Description
- Ideal for large-scale and rooftop installations
- High power
- Modules binned by current to improve system performance
- Excellent Glass Efficiency with anti-reflective coating
- Excellent temperature performance
- Improved low light performance
Description
| Cell Type | Half cut Mono PERC |
|---|---|
| Weight (kg) | 29 Kg. |
| Dimensions** | 2278x1134x35 mm |
| Warranty | ALMM Approved List by MNRE* | Module Efficiency up to 17.26% | Power Tolerance up to 4.99W | 25 Years Performance Warranty | 10 Years Product Warranty PID Resistant |
MODULE MECHANICAL CHARACTERISTICS
| Frame material | Anodized Aluminium Alloy |
|---|---|
| By-Pass Diodes | 3 Pcs |
| Connectors | MC4 Compatible |
| Cable | 4 mm² (IEC) - Length 0.35 mtr (Potrait)/ 1.4mtr(Landscape) |
| Junction Box | IP68 Split JB |
| Front Cover | 3.2 mm ARC Glass |
TEMPERATURE COEFFICIENT
| Nominal Operating Cell Temperature | 42 ± 2°C |
|---|---|
| Temperature Co-efficient (Pmax) | -0.36% /°C |
| Temperature Co-efficient (Voc) | -0.36% /°C |
| Temperature Co-efficient (Isc) | +0.06% /°C |
| NMOT/NOCT (Isc) |
