Description
G12R TOPCON technology delivers exceptional efficiency and performance for residential and commercial solar installations. These 625W bifacial glass-laminate panels maximize energy generation from both front and rear surfaces, capturing reflected light from ground and surrounding surfaces.
Non-DCR design ensures compatibility with standard inverter systems without additional equipment. The LUM 625TG132 specification represents premium-grade construction with enhanced durability and weather resistance.
Bifacial configuration increases annual energy yield by up to 25% compared to monofacial alternatives, making these panels ideal for open-field installations, rooftops with reflective surfaces, and ground-mounted systems.
Built for long-term reliability with robust frame construction and advanced cell technology. Perfect for customers seeking maximum power output and superior return on investment in solar energy systems.
Description
| Glass | Front 2.0mm ARC; back 2.0mm Non-ARC |
|---|---|
| Cell Type | TOPCON (N-Type) |
| Product Warranty (Years) | 12 Years |
| Performance Warranty (Years) | Linear Performance warranty for 30 Years with 1% for 1st year degradation and 0.45% from year 2 to 30 |
| Operating Temperature - Charge | -40°C to +85°C |
| Module Efficiency | 23.14 |
| Short-circuit current Isc (A) | 16.180 |
OPERATING CONDITION
| Maximum system voltage (UL & IEC) | 1500 |
|---|---|
| Maximum series fuse rating (A) | 30A |
MODULE MECHANICAL CHARACTERISTICS
| Module weight | 32.5 Kg |
|---|---|
| Number of cells & size | High quality Encapsulant |
| Frame material | Anodized Aluminium |
| Cable | 300mm length cables (+ve and -ve Terminal), MC4 Compatible/ MC4 Connectors |
| Junction Box | IP 68, Split Junction Box with individual bypass diodes |
| Encapsulant Material | Glass |
Dimensional & Packing Details
| Modules/ Pallet (UL & IEC) |
|---|
