Description
High Return:
1. Max efficiency 98.3%, Battery efficiency 97.5%
2. 5 basic modes to meet the needs of various scenarios
3. Smart TOU mode, further increasing revenue
High Capability:
1. Up to 40kW output power in backup port with grid supply
2. Save cost of separating loads, freedom of electricity in case of power failure
3. Supports SG Ready heat pump and smart load control
4. Three-phase unbalance capacity, single-phase up to 50% of rated power
High Protection:
1. Standard AFCI to protect your home
2. Built-in Type II SPD on DC side
3. IP66 protection for challenging environments
Description
| Brand | CHINT power |
|---|---|
| DC Switch | Support |
| IP Rating | IP66 |
| Weight (kg) | ≈37kg |
| AC Short-Circuit Protection | |
| Surge Protection | AC Type II, DC Type II |
| AFCI | Support |
| Cooling Method | Forced airflow |
| Topology | Non-Isolated |
| Noise Emission (typical)(dB) | <45dB |
| Operating Temperature Range (°C) | -25o C-60o C |
| Communication | RS485,CAN, WIFI/4G(optional) |
| Display | LED&APP |
| Safety | IEC62109-1&2, IEC61000, IEC 62477, IEC61727/62116, IEC 61683, IEC63027 |
| Anti-islanding Protection | Support |
| AC Short Circuit Protection | Support |
MODULE MECHANICAL CHARACTERISTICS
| Module dimensions L×W×H (mm) | ≈580/500/250mm |
|---|
