Description
APS offers high-quality, grid-connected solar inverters, locally manufactured for both residential and commercial use. With a wide range of inverters from 1kW to 100kW, including single-phase and three-phase options, we ensure superior performance and integration. Our inverters boast an impressive 98.5% efficiency and come with advanced features like Wi-Fi and GPRS connectivity. Backed by reliable after-sales service and 10-year warranty*, APS solar inverters guarantee top performance and long-term reliability
Description
| DC Switch | Optional |
|---|---|
| Weight (kg) | 15.5 |
| Dimensions** | 370*180-183.5 |
| Warranty | 10 Years |
| Humidity | 0~100( No Condensation) |
| Max.DC Power(kW) | 18000 |
| Rated Output Power (kW) | 12000 |
| Max.Output Apparent power (VA) | 13200 |
| Max.Output Current (A) | 19.1 |
| Energy Source | GRID-CONNECTED PV |
| Max.DC Input Voltage (V) | 1100 |
| Start-up DC Input Voltage (V) | 140 |
| Rated Input Voltage (V) | 600 |
| MPPT OperaƟng Range (V) | 140 ~ 1000 |
| Max.DC Input Current (A) | 14 |
| Max.Short-Circuit Current (A) | 18.2 |
| Number of MPPT / Number of strings | 2/1+1 |
| Rated Grid Voltage (v) | 3/N/PE, 220/380, 230/400, 240/415 |
| Rated Grid Frequency (Hz) | 50/60 |
| Rated Output Current (A) | 17.4 |
| Power Factor | 1 (Adjustable from 0.8 leading to 0.8 lagging) |
| Total Harmonic Distorion (THDi) (%) | <3 |
| MPPT EFFICIENCY | 99.08 |
| Euro EFFICIENCY | 97.8 |
| Max.EFFICIENCY | 98.6 |
| Insultation Monitorin | Yes |
| Residual Current Monitoring | Yes |
| DC Reverse Polarity Protection | Yes |
| Anti - Islanding Protection | Yes |
| AC Overcurrent Protection | Yes |
| AC Overvoltage Protection | Yes |
| Surge Protection | DC/AC : Type || |
| AFCI | Op |
| Topology | Transformerless |
| Max.OperaƟng Altitude (m) | 3000 |
| Operating Temperature Range (°C) | -25~60 |
| Ingress Protection | IP65 |
| Internal Consumption at Night (W) | <3 |
| Monitoring Module (W) | WIFI / 4G (Optional) |
| Communication | RS485, Meter / DRM, Estop |
| Display | LCE, Touch Key, App, Website |
| Safety | EN/IEC 62109-1/2, BIS IS 16169, BIS IS 16221-1/2 |
| EMC | EN 61000-6-1/2/3/4 |
| Grid Regulation | AS/NZS-4777.2, C10/11, EN50549-1, VDE-AR-N4105, RD 1699, CEI 0-21, NB/T 32004, VDE V 0126-1-1, UTE C 15-712-1 |
