Description
The NXIT130 Single Phase Grid Tie Inverter is engineered for seamless integration with your solar power system. This compact inverter converts DC power from your solar panels into clean AC electricity that feeds directly into the grid, maximizing your energy output and reducing dependency on conventional power sources.
Designed for residential and small commercial installations, the NXIT130 delivers reliable performance with advanced monitoring capabilities. Its robust construction ensures durability in India's diverse climate conditions, while intelligent grid synchronization technology protects your system and maintains power quality standards.
Ideal for rooftop solar setups, this grid-tie inverter helps you achieve energy independence while contributing to a sustainable future. With efficient power conversion and user-friendly operation, the NXIT130 is your smart choice for solar energy solutions.
Description
| Dimensions** | 480W *476H *157D |
|---|---|
| Max.DC Power(kW) | 15.0 |
| Rated Output Power (kW) | 10 |
| Max.DC Input Voltage (V) | 1000 |
| Number of MPPT / Number of strings | 2 |
| Power Factor | 0.8 …1... 0.8 |
| Total Harmonic Distorion (THDi) (%) | < 5% |
| MPPT EFFICIENCY | >99.9 |
| Max.EFFICIENCY | 98.4% |
| Cooling Method | Smart Cooling |
| Topology | Transformerless |
| Max.OperaƟng Altitude (m) | 2000m |
| Operating Temperature Range (°C) | -25°C to 60°C |
| Ingress Protection | IP65 |
| Internal Consumption at Night (W) | < 0.2 W |
| Display | LCD |
| Safety | BIS Certi ed as per IS/IEC standards |
| MPPT Voltage Range [V] | 160-850 |
| Start-up Voltage [V] | 125 |
| Noise (dB) | <25dBA |
