Description
Touch Energy Lithium batteries have a significantly higher cycle life than lead-acid batteries. This means that our batteries can support a higher number of complete charge & discharge cycles. Lithium-ion batteries are cleaner, live longer, recycle better, and require much less maintenance
Description
| IP Rating | IP63 |
|---|---|
| Cell | 32650-3.2V-6000mAh |
| Weight (kg) | 27 kg / Remark - ±5% |
| Nominal Voltage | 73.6 VDC |
| Dimensions** | 315 (L) x 235 (B) x 235 (H) mm / Remark - ±5 mm |
| Communication | CAN, RS485, UART, BLUETOOTH |
| Module Configuration (°C) | 23S 6P |
| Installed Energy (°C) | 2.64 KWh |
| Usable Energy (°C) | 2.38 KWh / Remark - @ 90% |
| Operating Voltage Range (°C) | 63.25 ~ 83.95 VDC |
| Rapid Charge Current(°C) | 18 A / Remark - @ 0.5C |
| Pulse Discharge Current (°C) | 70 A / Remark - ≤ 2S |
| Rated Discharge Power (°C) | 2.64 kW |
| Rated Discharge Current (°C) | 36A |
| BMS Features (°C) | Deep discharge & Over Charge, Cell Balancing & temperature compensation, short circuit |
| Cycle Life @ DoD 90% (°C) | ≥2,000 cycles / Remark - @ 25±3°C, 0.2C/1C |
