Description
| Brand | Boson Mega |
|---|---|
| Battery Capacity (kWh) | 129.04kWh |
| Weight (kg) | 1000 Kg |
| Dimensions** | 1704 X 1524 X 640 mm |
| Cycle life | ≥6000 cycles @ 70% SoH |
| Communication Interface | RS485/ CAN |
| Operating Temperature - Charge | 0~45 °C |
| Storage Temperature | 0~35 °C |
| Cooling Type | Forced air cooling |
| Battery Protections | Over-current, Over-voltage, Short-circuit, Under-voltage |
| Warranty | 10 Years |
| Module & cell compliance | UN 38.3, UL, BIS, IEC |
| Ingress Protection Class | IP20 |
| Cluster capacity range | 129.04kWh |
| Max. no. of clusters in parallel | 30 |
| Nominal cluster voltage | 614 V |
| Minimum operating cluster voltage | 700 V |
| Maximum operating cluster voltage | 518 V |
| Standard charge current | 105 A |
| Standard discharge current | 105 A |
| Maximum charge/discharge current | 210 A |
